Ortronics Clarity 6 Modular Patch Cord, 10', blue

(0)No Reviews yet
$16.95
SKU: ORT-MC610-06
MANUFACTURER: Ortronics
MPN: ORT-MC610-06
NOTE: Return Restrictions May Apply

Ortronics Clarity 6 Modular Patch Cord, 10', blue

Features

  • ETL third party tested and verified to TIA/EIA 568B.2-1 Category 6 component specifications: Ensures Category 6 component performance.
  • Each cord is factory tested: Ensures every cord shipped meets Category 6 component specifications.
  • Center tuned technology: Elevates the performance of Clarity 6 connector union.
  • Paralign 2 pair-positioning technology: Maintains pair integrity through the plug termination allowing mating hardware to be designed/tuned to these cords.
  • Snagless plug design: Protects plugs when pulling through pathways or cable managers.
  • Premium conductor cordage: Reliable performance and durable cord life.
  • Compatible with both T568A and T568B wiring: Provides universal wiring ability.
  • Improved signal to noise ratio: More transparent signal path is field measurable in a link or channel.
  • Backwards compatible to Category 3, 5, and 5e: Supports lower category installations and components. .
  • supports IEEE 802.3af,at and pening bt standards : Supports current and pending higher power PoE requiremsts .

Clarity 6 Modular Patch Cord, blue, 10', Category 6, four-pair UTP stranded 24 AWG PVC/CM, center tuned with Clarity 6 connecting hardware for optimum Category 6 installed performance using Ortronics Paralign 2 pair-positioning technolgy

GENERAL INFO:
  • Cable Type: Four-pair stranded UTP non-plenum
  • Color Cable Jacket: Blue
  • Performance Category: Cat 6 component compliant
  • Termination: 8-Pos Mod
  • Typical Applications: IEEE 802.3 1000Base-T (Gigabit Ethernet), TIA/EIA-854 1000Base-TX, ATM CB1G, IEEE802.3af,at & pending bt PoE standards
  • Product Series: Clarity
  • Type: Patch Cords and Cables

CORD INFORMATION:
  • Connector Type End One: Plug, HSG, eight-contact, RJ45, high performance
  • Connector Type End Two: Plug, HSG, eight-contact, RJ45, high performance
  • Jacket Rating: CM
  • Cord Length US: 10'
  • Min Bend Radius: 1.00"
  • Pinning: Straight 1-1, 2-2, 3-3, etc.

TECHNICAL INFORMATION:
  • Category Rating: Cat 6 component compliant
  • OhmValue: 100 Ohm
  • Performance Rating: Cat6
  • Wire Gauge: 24 AWG
