Ortronics Clarity 6 Modular Patch Cord, 7', blue
Ortronics Clarity 6 Modular Patch Cord, 7', blue
Features
- ETL third party tested and verified to TIA/EIA 568B.2-1 Category 6 component specifications: Ensures Category 6 component performance.
- Each cord is factory tested: Ensures every cord shipped meets Category 6 component specifications.
- Center tuned technology: Elevates the performance of Clarity 6 connector union.
- Paralign 2 pair-positioning technology: Maintains pair integrity through the plug termination allowing mating hardware to be designed/tuned to these cords.
- Snagless plug design: Protects plugs when pulling through pathways or cable managers.
- Premium conductor cordage: Reliable performance and durable cord life.
- Compatible with both T568A and T568B wiring: Provides universal wiring ability.
- Improved signal to noise ratio: More transparent signal path is field measurable in a link or channel.
- Backwards compatible to Category 3, 5, and 5e: Supports lower category installations and components.
Clarity 6 Modular Patch Cord, blue, 7', Category 6, four-pair UTP stranded 24 AWG PVC/CM, center tuned with Clarity 6 connecting hardware for optimum Category 6 installed performance using Ortronics Paralign 2 pair-positioning technolgy
GENERAL INFO:
CORD INFORMATION:
TECHNICAL INFORMATION:
- Cable Type: Four-pair stranded UTP non-plenum
- Color Cable Jacket: Blue
- Performance Category: Cat 6 component compliant
- Termination: 8-Pos Mod
- Typical Applications: IEEE 802.3 1000Base-T (Gigabit Ethernet), TIA/EIA-854 1000Base-TX, ATM CB1G
- Product Series: Clarity
- Type: Patch Cords and Cables
CORD INFORMATION:
- Connector Type End One: Plug, HSG, eight-contact, RJ45, high performance
- Connector Type End Two: Plug, HSG, eight-contact, RJ45, high performance
- Jacket Rating: CM
- Cord Length US: 7'
- Min Bend Radius: 1.00"
- Pinning: Straight 1-1, 2-2, 3-3, etc.
TECHNICAL INFORMATION:
- Category Rating: Cat 6 component compliant
- OhmValue: 100 Ohm
- Performance Rating: Cat6
- Sort Termination: 3
- Wire Gauge: 24 AWG
