Listen Stationary FM Transmitter - 72 Mhz
Features
- Look & Listen (TM) LCD display for quick channel, programming, and channel lock status information
- Balanced and unbalanced audio inputs allow for use with any audio source
- Built-in auto processor optimizes audio (voice or music) prior to transmission
- 57 available, selectable channels
- VU level meter and test tone for simple installation and set up
Offering outstanding audio clarity, digital signal strength, and 57 selectable channels, the LT-800 is a perfect RF transmitter choice for a wide range of applications. Connected to your main audio system, the LT-800 broadcasts strong, reliable audio to both belt pack receivers and stationary receivers, ideal for providing listeners with the best possible assistive listening experience.
Click Here for return policy information
LT-800 Stationary RF Transmitter (72 MHz), One (1) LA-207 Power Supply for LT-800, One (1) Line Cord, One (1) Quick reference card
Frequency Response: 50 Hz - 15 kHz (±3 dB)
Signal-to-Noise Ratio: SQ enabled 80 dB, SQ disabled 60 dB
Audio Input 1: Rear panel, one (1) Female XLR or 1/4 in combo connector, balanced, 0 / -55 dBu (line/mic) nominal input level adjustable, -30 / +21 dBu (line/mic) maximum input level, impedance 20k / 1k ohm (line/mic), phantom power +12 VDC
Audio Input 2: Rear panel, two (2) phono connectors, unbalanced, -10 / +10 dBu nominal input level adjustable, +30 dBu maximum, impedance 100k ohm
Audio Processing: Compression can be turned on/off, slope internally adjustable from 1:1 to 4:1, default 2:1
Contour: Cuts and boosts frequencies above 5 kHz
Distortion:< 2% total harmonic distortion (THD) at 80% deviation
Audio Output: Input 1 and input 2, mixed output (rear panel), two (2) phono connectors, unbalanced, -10 dBu nominal output level, +15 dBu maximum, impedance 10 ohm
Headphone Output: Front panel, one (1) 3.5 mm (0.14 in.) stereo connector, unbalanced, adjustable output level, +3 dBu maximum, impedance 10 ohm
User Controls: Front Panel: Power, test tone on/off, channel up/down, input levels, mix level, contour, monitor volume controlRear Panel: Input 1 Level, (Line, Mic, Mic-Phantom Power), Input 2 level (-10 / +10 dBu), RF power level (low, mid, high)
Frequency Range: 72.025 - 75.950 MHz
Number of Channels: 17 wide band, 40 narrow band
Transmission Range: Up to 305 m (1,000 ft.)
Output Power: 80,000 uV at 3 m
Number of Simultaneous Transmitters: 6
Power Supply: In line power supply, Listen part number LA-207
Width: 21.5 cm (8.50 in.)
Height: 4.5 cm (1.75 in.)
Depth: 23 cm (9.13 in.)
RF: FCC Part 15, Part 90, Industry Canada
